Product Installation:
Model meaning
The ZN63 high-voltage circuit breaker (often also known as the VS1 circuit breaker, VS1 being its most common model designation) is an indoor-installed medium-voltage circuit breaker employing vacuum arc-extinguishing technology. It is widely used in three-phase AC 50Hz power systems with rated voltages from 3.6kV to 12kV, serving as a protective and control device for power equipment, and is one of the core switching devices in modern substations and industrial and mining enterprise power distribution systems.
General product information
Place of Origin: |
5th Floor, No. 3, Jinghong West Road, Liushi Town, Yueqing City, Wenzhou City, Zhejiang Province |
Brand Name: |
MINGTUO |
Model Number: |
VCB(ZN63) |
Certification: |
IOS CE ROHS |
Product Commercial Terms
Minimum Order Quantity: |
1 |
Price: |
500$ |
Packaging Details: |
Wooden box packaging |
Delivery Time: |
Within fifteen days |
Payment Terms: |
100% prepaid, 70%/30%, 80%/20% |
Supply Ability: |
Available at any time |
Environmental conditions for use
Normal Operating and Installation Conditions
Ambient Air Temperature
The upper limit shall not exceed +40°C, the lower limit shall not fall below -5°C, and the 24-hour average value shall not exceed +35°C. Note: Operating conditions with a lower limit of -10°C or -25°C must be confirmed by the user.
Operating conditions exceeding the upper limit of +40°C or falling below -10°C or -25°C must be negotiated with the user. 3.2 The installation location must not exceed 2000m above sea level.
Atmospheric Conditions
The relative humidity must not exceed 50% at an ambient air temperature of +40°C. Higher relative humidity is permitted at lower temperatures. The maximum average relative humidity in wet months is 90%, and the average minimum temperature for that month is +25°C. Condensation on the product surface due to temperature fluctuations must be considered. If the temperature exceeds these limits, the user must consult with the user. 3.4 Protection Grade: IP30
Usage Category: Class B or Class A
Installation Category
Circuit breakers and undervoltage releases with a rated operating voltage of 660V (690V) or less, and the primary winding of the power transformer, are intended for installation category N; auxiliary circuits and control circuits are intended for installation category III.
Installation Conditions
Circuit breakers must be installed in accordance with the requirements of this manual. The vertical tilt of the circuit breaker must not exceed 5° (mining circuit breakers must not exceed 15°).
1. Competitive pricing, factory quality assurance
2. Customizable housings
3. Extensive production and installation experience, ready to provide guidance
4. Assistance with commissioning and selection
Real photos
Q: What is the voltage/current range of this product? What is its breaking capacity?
A: Please contact customer service for details.
Q: What is the minimum order quantity? Do you accept sample orders?
A: The minimum order quantity is 1 set, and we accept sample orders.
Q: What is the warranty period? How do I apply for a warranty?
A: The product warranty is 1 to 2 years. Please contact customer service directly to apply.
Q: Do you have CE, RoHS, UL, or other certifications? Can you provide certificates?
A: We have CE and RoHS certifications and can provide certificates.
Q: Does the price include tax/shipping?
A: The price does not include shipping/tax.
Q: What notable clients or project examples have you worked with?
A: State Grid Corporation of China, Chint Group.
